Astm Spring Steel Uniformly Heated 28-34 HRc
SAE-AISI 5160 steel is an alloy steel formulated for primary forming into wrought products. 5160 is the designation in both the SAE and AISI systems for this material. G51600 is the UNS number. It can have a moderately low ductility among the SAE-AISI wrought steels in the database.
The properties of SAE-AISI 5160 steel include four common variations. This page shows summary ranges across all of them. For more specific values, follow the links immediately below. The graph bars on the material properties cards further below compare SAE-AISI 5160 steel to: SAE-AISI wrought steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.
Carbon steel is available as bright drawn key steel in flat and square sections. With medium tensile strength key steel is used widely in general engineering for components such as plain, gibhead, taper and parallel keys. Key steel is produced to the required tolerances as specified in British Standard BS46 and BS4235.Carbon spring steel specifications EN42, CS70, CS80, CS95 and CS100 are available as hardened and tempered spring steel strip, annealed spring steel strip, spring steel plate and spring steel sheet. EN43 spring steel is available in bar and plate. The grades commonly conform to BS970, BS1449, BS EN10083-1, BS EN10083-2, BS EN 10277 and BS EN 10278 standards.X120Mn12 1.3401 is a manganese steel with 1% carbon steel and an 11% to 14% manganese content supplied in plate. Offering excellent work hardening properties high manganese steel can be supplied in full plates or cut to your requirements.
With an objective to fulfill ever evolving demands of customers, we have been able to manufacture and supply premium quality SAE 5160 Spring Steel to our prestigious clients. It is widely used in metallurgical, mechanical, electrical construction field, ships, military uses and automobile rear of products. Apart from this, it is well known for its High yield to tensile strength ratio, great toughness and high tensile strength.
SAE 5160 Spring Steel is fabricated through superior quality components that are in compliance with international standards. Also, it is well tested on parameters of quality and durability to ensure flawless products to our customers.
Technical Specification
|
Grade
|
C
|
Mn
|
P
|
S
|
Si
|
Cr
|
|
5160/ 5160H
|
0.55-0.65
|
0.65-1.00
|
0.035max
|
0.035max
|
0.15-0.35
|
0.60-1.00
|
AISI 5160 Steel is a high quality Cold work Spring Steel, It belong to the high quality high carbon alloy Spring Steel. Oil Quenched & Tempered Hardness is 28-34 HRc. 5160 steel Annealing delivery hardenss less than 250HB.
